| Parameter |
SCR3310v2.0 Details |
|
| Host Interface |
USB 2.0 full speed |
| Supported Standards |
ISO/IEC 7816 Part 1 to 4, EMV 2011 Ver 4.3 Level 1 (compliant) |
| Supported Tag ICs |
All major ISO/IEC 7816 compliant smart cards and synchronous cards |
| Smart Card Protocols |
T=0, T=1, synchronous cards I2C and 3-wire |
| Smart Card Interface Speed |
• Up to 600 kbps
• TA1=97 |
| Smart Card Clock Frequency |
ISO/IEC 7816 compliant; Operates up to 16 MHz |
| Supported Smart Card Types |
5V, 3V, and 1.8V; ISO 7816 smart card Class A, B, and C |
| Power to Smart Card |
60mA in Class A; 55mA in Class B; 35mA in Class C |
| Smart Card Detection |
Card present switch; Automatic power on/off; Short circuit protection |
| Card Size |
ID-1 |
|
Contact Type |
• 8 pin ID-1 Sliding Contact Socket
• C4/C8 support
• Card present switch |
|
PC/SC DRIVER |
PC/SC Specification Ver. 2.01.14 for: |
| • Windows® 7/8/10/11 (32 and 64 bit)
• Windows® Server 2008/2012/2016/2019
• Windows® 6.0, 7.0
• WindowsXP |
• MacOS 10.9.x – 12.1.x
• Linux 2.6.x, and 3.x, 4.x, 5.x (32 and 64 bit)
• Android 4.0 and higher |
|
Software |
• PC/SC API
• CT-API (through wrapper on top of PC/SC)
• M-Card API (through wrapper on top of PC/SC) |
| Power Supply |
USB Bus-powered |
| Power Consumption |
<6mA excluding smart card; <20mA with standard card; <500μA in standby mode |
| Dimensions |
72 x 70 x 14 mm (2.83 x 2.75 x 0.55 in) |
| Weight |
60 grams |
| Operating Temperature Range |
0° to 50°C (32° to 122°F) |
| Storage Temperature Range |
-20° to 60°C (-4° to 140°F) |
| Operating Humidity Range |
Up to 90% RH non-condensing |
| Durability |
Sliding contact 100,000 card insertions |
| MTBF |
100,000 hours |
| Cable |
1.5m cable with USB Type A or Type C connector |
| Status Indicator |
Green LED |
| Firmware |
SmartOS™ |
| Firmware In-Field Upgradeable |
No |
| Systems/Standards |
EMV 2011 Ver 4.3 Level 1(compliant only), ISO/IEC 7816, USB 2.0 Full Speed, CCID, Microsoft® HCK |
| Regulatory/Environmental |
CE, FCC, UL 60950, IEC 62368-1, GSA APL, RoHS2, REACH, WEEE |
| Product Part Number |
905331 (Type A); 905331-6 (Type C)
|
